UPS Inverter Charger with MPPT Solar Charge Controller built in All in One Solar System

  • GA SERIES

  • NOVA

Availability:
Quantity:

High frequency MPPT hybrid solar inverter 5.5KW, Parallel function optional

Smart Wifi APP Monitoring Function Optional


It is a new type of hybrid solar energy storage inverter that integrates solar energy storage & city power charging energy storage and AC pure sine wave output.


It adopts DSP control and has high response speed through advanced control algorithms, high reliability and high industrialization standards.

There are four optional charging modes: PV, city power priority, PV energy priority or city power & solar. Two output modes of inverter and city power are optional to meet different application needs.
The solar charging module adopts the latest optimized MPPT tracking technology, which can quickly track the maximum power point of the photovoltaic array in any environment, obtain the maximum energy of the solar panel in real time, and has a wide MPPT voltage range.


Model
Rated Power
Input /  Output Voltage
Grid Charging Current
MPPT Controller
Max PV Input Voltage
NV-GA-3500W
3500W
24Vdc TO 230Vac
60A
MPPT 60A
145V
NV-GA-5500W
5500W
48Vdc TO 230Vac
80A
MPPT 80A
450V
NV-GA-5500W In Parallel
5500W
48Vdc TO 230Vac
80A
MPPT 80A
450V

20

英文-10英文-5英文-6GA-英文_08英文-2GA-英文_09GA-英文_07

GA-英文_12
